SCR Diode Tester

Product Overview

SCR’s and Diodes are used in the power sections of various power systems. A SCR Diode Tester is an important equipment to determine if a SCR, diode or MOV is defective in a power circuit. It is difficult and time consuming to troubleshoot SCR’s and Diodes with a digital meter.

It is important to determine the true peak inverse voltage of a SCR or a diode. Our SCR Diode Tester is an excellent peak inverse voltage tester.

It is important to group SCR’s or Diodes with adequate peak inverse voltages for optimum operation of a rectifier circuit. Our SCR Diode Tester is a reliable rectifier tester and helps isolate marginal parts among the group. The SCR tester also provides the SCR gate trigger voltage and the current flow at that trigger voltage.

CEHCO is a SCR Diode Tester manufacturer. This tester is a leader in the industry and has been used for more than 20 years. It was the first of its kind built. This SCR Diode Tester is a compact durable unit and ideal for any maintenance department. This compact 6" x 12" x 17" inch unit operates on 120 VAC, 60 Hz line voltages.  An easy to use instruction plate is included inside the front cover.  The unit comes with test leads and a compressor block. This portable SCR and Diode test equipment makes it easy to isolate and troubleshoot diodes, SCR’s, and MOV's. The photo of the SCR Diode Tester is shown below:

The SCR Diode Tester comes in five models with peak voltages ranging from: 2000 V, 3000 V, 4000 V, 5000 V and 6000 V.

• T101R/2V                    ...                     For 2000 VAC peak voltage test
• T101R/3V                    ...                     For 3000 VAC peak voltage test
• T101R/4V                    ...                     For 4000 VAC peak voltage test
• T101R/5V                    ...                     For 5000 VAC peak voltage test
• T101R/6V                    ...                     For 6000 VAC peak voltage test

Please review the demo at http://www.cehco.com/?page_id=186 to see how this instrument can be suitable for your application.

This unit has been the industry standard for the last 20 years, and is a must for every maintenance department. If you would like more information, please contact us toll free (800) 595-7096, or send us an email at info@cehco.com.
