CEHCO has considerable experience in building 6 Diode bridge assemblies. Shown below is a six diode bridge assembly using encapsulated diode modules. Each diode is rated for 166 Amps. The output power is estimated at 166 Amps.
The details of the six diode bridge assembly, part number 12W-166-1200PIV-1F-120 are shown below:
Specifications:
- Six Diode Bridge Assembly, P/N 12W-166-1200PIV-1F-120
- Each diode is rated for 166 Amps, 1200 PIV
- Our “W” heat sink, 11.81” long
- Customer to provide 120 VAC to the fan
We keep all materials (i.e. diodes, SCR’s, heat sinks, etc.) in stock for immediate assembly. We look forward to working with your engineers in designing a rectifier stack that is appropriate for your system requirements. Rectifier stacks listed above are for a 1000 VDC maximum output voltage applications only. For higher voltage applications such as 5000 VDC, please refer to our High Voltage Rectifier Stack. To discuss your specific rectifier stack requirements, please contact us toll free at (800) 595-7096, or send us an email at info@cehco.com
