CEHCO builds many Transformer Rectifier assemblies which has a single phase power input. With this design a four Diode Rectifier assembly is needed. The output ripple after the Bridge Rectifier Assembly is 50%. This 50% rectified output is O.K. for certain motor applications, where a strict DC output with minimum ripple is not required. If output ripple needs to be reduced, an output filter capacitor can be added.
The block diagram of the unregulated transformer rectifier assembly is shown below:
The photo of the unregulated transformer rectifier assembly, part number 18213PS is shown below:
Specifications:
- Unregulated Transformer Rectifier Assembly, P/N 18213PS
- Input: 120 VAC, 1 PH, 60 Hz
- Output: 120 VDC +/- 10%, 16.7 Amps.
- Ripple: 50%.
- All input output connections are provided on the terminal block.
- Open panel construction: 17″ L x 14″ W panel
